S-eWAY Rigid

Up to 400km Range

Fast Charge 45 min for 200 km

Up to 44 t GCW when towing

A battery layout for every application

Cab completely free of noise

A layout for every application

Battery pack	2 + 1 + 2	3 + 1 + 3	3 + 1 + 0
Energy on Board Nominal	350 kWh	490 kWh	280 kWh
Energy on Board Usable	300 kWh	420 kWh	240 kWh

The Microwast Battery have been designed for a lifetime of 12 years and 1.2 mln km, with a 70% SoH at End of Life.

Mech E-PTO for Refuse Collection, Hooklifter, Skiploader, Crane, Tipper

The Mech e-PTO can provide 60kW continuously and peak power of 100kW to drive hydraulic pumps for even the most demanding applications. You can select from 3 locations to suit the body requirements: on the right-hand sidemember in front of the battery pack or behind or behind the cab. All can be with pump connections.

HV e-pto for Refrigerated mission

Applications such as refrigerated bodies, which work with 380V 3 phase AC, can specify the HV e-PTO. Providing up to 20kW continuous power, this is the most energy efficient solution.

Battery relocation rearwards for applications such as Cranes

When an application requires space for stabiliser legs to the rear of the cab, this option moves the batteries rearwards by 270mm to achive a space of 500m between the front mudguards and the batteries. Ideal for the stabiliser legs.

Low Voltage PTO

Applications that use a low voltage PTO (for example a taillift) can specify an option providing up to 300Amps at 24 volts. VEEHH tail lift provision is also available for those markets and bodybuilders where it is required.

Diesel-like Payload

The higher GVW and GCW permitted by the EU for Zero emission vehicles means that payload is equivalent to the corresponding diesel vehicle with no compromise.

Range up to 400km in Urban & Regional Missions

All the Energy On-Board that you need. From 350kWh standard with 5 batteries, you can choose a 7 battery 490kWh arrangement for missions requiring greater range up to 400km or extensive PTO use.

All the Power you need

The correct amount of energy

Battery pack	2 + 1 + 2	3 + 1 + 3	3 + 1 + 0
Energy on Board Nominal	350 kWh	490 kWh	280 kWh
Energy on Board Usable	300 kWh	420 kWh	240 kWh

The Microwast Battery have been designed for a lifetime of 12 years and 1.2 mln km, with a 70% SoH at End of Life.

Energy saving features

Energy management is key to Electric vehicle operation and features such as 7 position Rengenerative braking control ensure that energy is not wasted. Eco mode ensures that the driver doesn’t use more energy than necessary. Smart route planning drive also assist. Features such as mirror cams improve areodynamics so further assisting energy management.

Easy Charging

Charge your vehicle with a DC charger. You just need to activate the Electric Parking Brake and plug the vehicle to the charging station.
You can opt for slow overnight charging and have your vehicle ready for the following day or alternatively with a high power charging during drivers’ mandatory break boosting the vehicle range in a very short time.

DC charging up to 350 kW

CCS type 2 charging connector conveniently located on LHS behind the cab allows DC charging at up to 350kW. This will enable the vehicle to recharge in a short period and with 5 battery pack achieve 20% to 80% charge during the statutory 45 min driver breaks.

Depot charging

IVECO Certified Charging solutions is your stress free answer to all your charging needs.
Iveco has partnered with charger manufacturers to offer tailored solutions for installing and maintaining charging points in your depot.

Exceptional comfort on board

The entire driving area has been designed to provide space and excellent visibility. Every single detail has been designed to meet the needs and expectations of the driver. Steering wheel and controls ensure comfort and safety for the driver in every operation.
The dashboard is customizable with new materials and colours, with a fully adjustable steering wheel, full TFT instrument cluster and infotainment.
State of the art “car like” feeling with more vertical steering wheel and lower driving position enhance comfort and responsiveness.
Choose between the leather or fabric upholstery of seats and discover the enveloping comfort of the cushions and the improved driving ergonomics. the new electric parking brake is engaging automatically to simplify operations and increasing safety.

Rest relax and sleep well
The symmetrical layout of the night area has been designed so you can enjoy a good night’s rest in great comfort. You can sleep soundly and safely with the the night-time safety lock integrated in the central locking system. The one-piece lower bunk is available with a choice of soft or hard mattress. The Smart or Comfort upper bunk can be used as a luggage compartment or a passenger bed.

Perfect lighting vs common
100% full LED – inside and out, including the marker lights – give you the perfect illumination inside the cab and on the road for safe night-time driving. LEDs also improve durability vs traditional solutions.

Everything in its place

The driving area had been redesigned to improve ergonomics.
The foldable table on the passenger side of the dash panel is ideal for those other work tasks in the cab that require a flat worksurface with a useful USB charging socket alongside.
The lower console integrates a convenient shelf with bottle holder, cup holder and background lighting.
Further storage is available above the windscreen and under the bunk.
The integrated HVAC system offers heating, ventilation and air conditioning with “Eco-Mode” function.

An extraordinary on-board experience with our new Digital Cockpit

The digital cluster provides all the usual vehicle information together with the information required to get optimal energy use from an electric vehicle such as battery state of charge, power flow and predicted range. In addition e PTO status is displayed.

Infotainment

Exteriors

You can personalise the external look you require for your company with glossy black finishes and metallic elements. The new IVECO logo is in matt gun metal finishes. Even the bumper is available in a choice of plastic or hybrid solutions with a choice of colours to match your requirements.
The front face includes headlamps with LED headlamps available as standard, radar for ADAS functions, steps and grab handles to access the windscreen. The side air deflectors are designed to keep the door and mirrors clear even in adverse weather conditions.
The new mirrorless cameras allow for better visibility for the driver and improve aerodynamics aiding fuel economy.

IVECO DRIVER PAL

The new IVECO DRIVER PAL is completely integrated in the vehicle. It is the pioneering digital travel companion from IVECO, built on Amazon Web Services setting new standards in the field of innovation for drivers by introducing voice command capability via Amazon Alexa* features.
With MYIVECO and MYCOMMUNITY skills, IVECO DRIVER PAL allows the driver to bring their digital life on board interacting with the vehicle and the rest of the community through Amazon Alexa* voice commands, Driving experience is more comfortable, safer and more relaxed with voice-enabled access to the brand’s ever-growing range of digital services and the extensive feature offering of Amazon Web Services and Amazon Alexa*.

* Amazon, Alexa, Echo and all related marks are trademarks of Amazon.com, Inc. or its affiliates.

No Noise, No Vibration

With no noise and no vibration from a diesel engine, driving becomes a pleasure and you will arrive at you destination less stressed and more relaxed.

Level 2 ADAS systems and general safety regulation compliance support the driver to be more comfortable and safer.

HIGHWAY ASSIST
Actively supports the driver in keeping to the centre of the lane so reducing driver fatigue thanks to the use of the Front Camera, Active Steering and the Capacitive Hands-off Detection. It can be automatically activated with the Adaptive Cruise Control.

ADAPTIVE CRUISE CONTROL WITH STOP&GO
Supports the driver in keeping to the desired speed along with maintaining a safe distance to the vehicle in front. It controls engine and braking power according to traffic conditions.

When in a queue, it will follow the vehicles in front and even auto-restart from stationary after up to a 3 second stop.

DDAW: Driver Drowsiness Attention Warning

Monitors the driver alertness and provides a warning when they are drowsy.

ALC: Alcohol Interlock Preparation

Is an alcohol interlock standardised interface for the fitment of compatible aftermarket or OEM alcohol interlock devices.

ISA: Intelligent Speed Assist

Aids the driver in observing the road speed limit, providing visual and acoustic feedback.

MOIS: Moving Off Info System

Detects nearby road users in the front blind spot zone, providing visual and acoustic warnings.

BSIS: Blind Spot info System

Detects road users moving at 5-20 km/h speed in the nearside blind spot zone, providing visual and acoustic warnings.

REV: Reversing Detection

Provides a clear view of road users and obstacles behind the vehicle when reversing, thanks to a camera placed in the rear crossmember.

ESS: Emergency Stop Signal

Warns the road users behind the vehicle via hazard lights, when braking heavily.

Lane Departure Warning System (LDWS)

Warns the inattentive driver of the departure of the vehicle from the lane when turn indicators are not activated

Electronic Vehicle Stability Control (EVSC) and Advanced Emergency Braking System (AEBS)

Recognizes a potential front collision, warning the driver and slowing down the vehicle as much as possible. Guaranteed full braking from 80 to 0 km/h.

The EVSC system monitors lateral loads and reduces power and applies brakes to control potential spins or rollover.

TPMS: Tyre Pressure Monitoring

Constantly monitors the status of PRESSURE and TEMPERATURE of the tyres and provides warning to the driver whenever a problem occurs.

The Tyre Pressure Monitoring System (TPMS) ensures that the tyre pressure is always the ideal one.

eStart Pack

eStart Pack is the entry point of Iveco Services world to provide an integrated mobility solution designed to make your life easier and your business more profitable. It includes:

IVECO ON Access
Access our IVECO On customer portal to view vehicle availability at a glance and to monitor charging and battery status of every vehicle in the fleet. Performance and driving style can be monitored helping to optimize energy efficiency.

Uptime Monitoring & Management
Thanks to predictive AI algorithms which monitor battery charging, use and parameters, IVECO Customer Uptime Center proactively monitor your vehicle and give you tips and suggestions to maximize Range and Lifespan.
The Remote Assistance Service save your time by fixing the fault remotely when it is possible.
Over-the-air updates enable software updates remotely to maximize your vehicle uptime.

Driver App
Designed to make your life easier. Energy management in your hand with visibility of battery status and range remaining. Evaluation, coaching and engagement to optimise driving style and reduce energy use. You can also activate Assistance Non-Stop, and access your vehicle’s diagnostics information remotely.

eRemote Control
Enhance your fleet management to maximise effiency monitoring driving mode and style. Review cab climate and ePTO use of vehicles individually or as the whole fleet to ensure your operation runs sustainably, efficiently and profitably.

eRemote Assurance
Proactive alerts inform you if there are critical battery levels and charging issues, ensuring visibility and control over your vehicle’s charging status and range.

Premium Services

Choose Premium Services and boost your business productivity. You can benefit of the following ones:

IVECO ON Plus
Enhances the experience with IVECO ON by providing the tracking of vehicles position with updates every 15 mins.

Professional Safe Report
Detailed report allows you to evaluate and improve your driving style reducing accidents and improving road safety.
This can lead to a reduction of insurance costs and less vehicle downtime.

Professional eReport
Comprehensive report which provides valuable insights into the energy usage and driver behaviour to optimize fleet operations for improved productivity, sustainability, and cost-effectiveness.

TomTom Live Services
In addition to all you expect from professional truck navigation, with the new S-eWay Rigid you have complete visibility on Range and Energy use Including total charging stops and duration.
Special functionalities are provided for vehicles with energy using equipment  to ensure mission accomplishment by factoring in to the route calculation the ePTO energy reserve protection.

Web API
Allow you to integrate your vehicle data directly into your preferred ICT solution. The integration with your systems allows you to instantly retrieve real-time vehicle data without requiring special adaptations of your vehicles.

ELEMENTS Maintenance & Repair
Tailored to your requirements to guarantee your vehicle’s maximum uptime and protect your business productivity.
